Automatic Tyre Killers
| Business Type | Manufacturer, Supplier |
| Click Here To View Catalog |  View |
| Material | Mild Steel |
| Paint | Spray |
| Mechanism | Electromechanical / Electro-Hydraulic |
| Power Supply | 220 Volt AC ±10%, 50 Hz (Single Phase) |
| Height Of Spike Above Block | 150 Mm (both Sides) |
| Spike Dimension | 150 Mm × 8 Mm (Thickness) × 4 Mm |
| Load Capacity | Steel Structure Capable Of Withstanding 40 Tons |
| Spike-to-Spike Distance | 100 Mm |
| Operation Through | Push Button Switches / Remote |
| System Width | 850 Mm |
| Gears | Moderate Mild Steel, Oil-filled And Sealed Composite Gear Drive Unit With Internal Locking Feature |
| Safety Features | Two-way Traffic Light, Beam Sensor |
| Power Failure Operation | Manual Operation By Hand |
| IP Rating | IP 53 |
| Operating Temperature | -15°C To +60°C |
| Business Type | Manufacturer, Supplier |
| Click Here To View Catalog | View |
| Blocking Width | 5 Meters |
| Wheel Load | 106 KN |
| Height Of Blade | 50 Cm |
| Make Of Blades | Heavy-duty Steel |
| Distance Between Blades | 175 Mm |
| Raising Time | 2 To 3 Seconds |
| Emergency Operation | Power Failure (manual Operation) |
| Hydraulic Device | Unit In Separate Protective Housing |
| Operation Through | Push Button Switches |
| Business Type | Manufacturer, Supplier |
| Click Here To View Catalog | View |
| Blocking Width | 6 Meters |
| Wheel Load | 50 ton |
| Height Of Blade | 500 mm |
| Make Of Blades | Heavy-duty Steel |
| Distance Between Blades | 190 mm |
| Raising Time | 2 To 3 Seconds |
| Emergency Operation | Power Failure (manual Operation) |
| Hydraulic Device | Unit In Separate Protective Housing |
| Operation Through | Push Button Switches |
| Blocking Width | 5 meters |
| Wheel Load | 106 kN |
| Height of Blade | 50 cm |
| Make of Blades | Heavy-duty steel |
| Distance Between Blades | 175 mm |
| Raising Time | 2 to 3 seconds |
| Emergency Operation | Power failure (manual operation) |
| Hydraulic Device | Unit in separate protective housing |
| Operation Through | Push button switches |
| Business Type | Manufacturer, Supplier |
| Click Here To View Catalog | View |
| Total Length/Clear Opening | 6 Mtr |
| Open/Close Time | 1-3 Sec |
| Material | Mild Steel |
| Paint | Spray Mechanism |
| Power Supply | 220v AC, 50 Hz |
| Height Of Spike | 150 Mm |
| Spike Dimension | 150mm X 16mm X 4mm |
| Load Capacity | 20 Ton |
| Spike To Spike Distance | 120mm-160mm |
| System Width | 450mm |
| Operate Through | Push Button Switch/Remote |
| Power Failure | Manual Operate By Hand |
| Load Test | ASTM A 370/17S |
| Bend Test | ASTM A370/IS:1786 |
| Yield Test | 433:1 MPA |
| Elongation | 19.50% |
| IP Rating | IP-53 |
| Working Temp | -15˚C To +60˚C |
| Business Type | Manufacturer, Supplier |
| Click Here To View Catalog | View |
| Total Length | 6 Mtr |
| Clear Opening | 6 Mtr |
| Open/Close Time | 1-3 Sec |
| Material | Mild Steel |
| Paint | Spray Mechanism |
| Power Supply | 220v AC, 50 Hz |
| Height Of Spike | 150 Mm |
| Spike Dimension | 150mm X 16mm X 4mm |
| Load Capacity | 50 Ton |
| Spike To Spike Distance | 120mm-160mm |
| System Width | 450mm |
| Operate Through | Push Button Switch/Remote |
| Power Failure | Manual Operate By Hand |
| Load Test | ASTM A 370/17S |
| Bend Test | ASTM A370/IS:1786 |
| Yield Test | 433:1 MPA |
| Elongation | 19.50% |
| IP Rating | IP-53 |
| Working Temp | -15˚C To +60˚C |
| Business Type | Manufacturer, Supplier |
| Click Here To View Catalog | View |
| Total Length | 5 Mtr |
| Clear Opening | 3 Mtr/2.5 Mtr, 5 Mtr/4.5 Mtr |
| Open/Close Time | 1-3 Sec |
| Material | Mild Steel |
| Paint | Spray Mechanism |
| Power Supply | 220v AC± 10,50 Hz |
| Height Of Spike | 150 Mm |
| Spike Dimension | 150mm×16mm×4mm |
| Load Capacity | 40 Ton |
| Spike To Spike Distance | 120mm-160mm |
| System Width | 550mm |
| Operate Through | Push Button Switch/Remote |
| Power Failure | Manual Operate By Hand |
| Load Test | ASTM A 370/17S |
| Bend Test | ASTM A370/IS:1786 |
| Yield Test | 433:1 MPA |
| Elongation% | 19.50% |
| IP Rating | IP-53 |
| Working Temp | -15˚C To +60˚C |
| Business Type | Manufacturer, Supplier |
| Click Here To View Catalog | View |
| Total Length | 6 Mtr |
| Clear Opening | 6 Mtr/5.5 Mtr |
| Open/Close Time | 1-3 Sec |
| Material | Mild Steel |
| Paint | Spray Mechanism |
| Power Supply | 220v AC, 50 Hz |
| Height Of Spike | 150 Mm |
| Spike Dimension | 150mm X 16mm X 4mm |
| Load Capacity | 20 Ton |
| Spike To Spike Distance | 120mm-160mm |
| System Width | 400mm |
| Operate Through | Push Button Switch/Remote |
| Power Failure | Manual Operate By Hand |
| Load Test | ASTM A 370/17S |
| Bend Test | ASTM A370/IS:1786 |
| Yield Test | 433:1 MPA |
| Elongation | 19.50% |
| IP Rating | IP-53 |
| Business Type | Manufacturer, Supplier |
| Click Here To View Catalog | View |
| Total Length | 5 Mtr |
| Clear Opening | 5 Mtr |
| Open/Close Time | 3-6 Sec |
| Material | Mild Steel |
| Paint | Spray Mechanism |
| Power Supply | 220v AC, 50 Hz |
| Height Of Spike | 150 Mm |
| Spike Dimension | 150mm X 16mm X 4mm |
| Load Capacity | 20 Ton |
| Spike To Spike Distance | 120mm-160mm |
| System Width | 450mm |
| Operate Through | Push Button Switch/Remote |
| Power Failure | Manual Operate By Hand |
| Load Test | ASTM A 370/17S |
| Bend Test | ASTM A370/IS:1786 |
| Yield Test | 433:1 MPA |
| Elongation | 19.50% |
| IP Rating | IP-53 |
| Working Temp | -15˚C To +60˚C |
| Business Type | Manufacturer, Supplier |
| Click Here To View Catalog | View |
| Total Length | 5 Mtr |
| Clear Opening | 5 Mtr |
| Open/Close Time | 3-6 Sec |
| Material | Mild Steel |
| Paint | Spray Mechanism |
| Power Supply | 220v AC, 50 Hz |
| Height Of Spike | 150 Mm |
| Spike Dimension | 150mm X 16mm X 4mm |
| Load Capacity | 50 Ton |
| Spike To Spike Distance | 120mm-160mm |
| System Width | 450mm |
| Operate Through | Push Button Switch/Remote |
| Power Failure | Manual Operate By Hand/manual Release Pump |
| Load Test | ASTM A 370/17S |
| Bend Test | ASTM A370/IS:1786 |
| Yield Test | 433:1 MPA |
| Elongation | 19.50% |
| IP Rating | IP-53 |
| Working Temp | -15˚C To +60˚C |
| Business Type | Manufacturer, Supplier |
| Click Here To View Catalog | View |
| Vehicle Passage Width | 3-9 Meters |
| Open / Close Time | 1-3 Seconds |
| Material | Mild Steel |
| Paint | Spray |
| Mechanism | Electromechanical |
| Power Supply | 220 Volt AC, 50 Hz |
| Height Of Spike Above Block | 150 Mm |
| Spike Dimension | 200 Mm X 10 Mm X 4 Mm |
| Load Capacity | 20 Tons |
| Spike-to-Spike Distance | 100 Mm |
| Operation Through | Push Button Switches / Remote |
| System Width | 500 Mm |
| Gears | Moderate Mild Steel, Oil-filled Composite Gear Drive Unit |
| Safety Features | Two-way Traffic Light, Beam Sensor |
| Power Failure Operation | Manual Operation By Hand |
| IP Rating | IP 53 |
| Operating Temperature | -15°C To +60°C |
| Business Type | Manufacturer, Supplier |
| Click Here To View Catalog | View |
| Material | Mild Steel |
| Color | Spray Paint |
| Mechanism | Electromechanical |
| Power Supply | 220 Volt AC, 50 Hz (single Phase) |
| Height Of Spike | 150mm |
| Spike Dimension | 200mm X 100mm X 4mm |
| Load Capacity | 50 Ton |
| Spike To Spike Distance | 100mm |
| Operation Through | Push Button Switches/Remote |
| Safety Features | Two Ways Traffic Light, Beam Sensor |
| IP Rating | IP53 |
| Operating Temperature | -15°C To +60°C |
Leading Manufacturers and Wholesaler of Automatic Tyre Killer from Delhi.
